Features
- Custom-built rigid ultra-lightweight open or cantilever 6061T6 aluminium frame.
- Folding adjustable height backrest with adjustable tension upholstery
- High performance rear wheels equipped with high-pressure clincher tyres. The anodized aluminium handrims and quick-release axles.
- Front forks with inset bearings. Semi-pneumatic front casters 4″ or 5″.
- Smart adjustability to keep the total chair under 9kg. 4.25″ of the centre of gravity, footrest height, backrest height and angle plus adjustable tension seat and back upholstery.
Specifications
| Frame: | Custom-built rigid ultra-lightweight open frame or cantilever design. Ergo seat option provides optimum positioning, good pressure distribution and better propulsion. |
| Frame Tubing: | 6061 T6 aluminum in 1-1/8″ tubing size. |
| Seat Width: | 18″ standard. |
| Seat Depth: | 18″ standard. |
| Back Height: | Adjustable (8″-11″,10″-14″, 14″-18″ or 16″ -20″) |
| Back Angle: | The back angle is adjustable on folding back with 5 settings and fixed on the fixed back. |
| Wheels: | Kenda Tyres |
| Camber Angle: | The centre of gravity adjustment is 4.25″. Camber choice of 0,3,6 or 9 degrees. |
| Footrest: | One piece tubular footrest or an adjustable angle footplate. |
| Product Weight Capacity: | 113kg |
